As our business continues to grow our focus is on providing white labeled Tier 3 IT support services, RMM as a service, and co-managed IT services. This blog will be highlighting tips for using a Bash script to forward Cisco Duo MFA logs into a self-hosted Wazuh SIEM.

We recently connected Duo to the onsite Wazuh server of a client working toward CMMC Level 2. Logging every MFA event and every admin change is part of the evidence an assessor wants to see (NIST 800-171 controls 3.3.1 and 3.5.3). Duo ships an official tool for exactly this. Getting it to produce real Wazuh alerts took some work, so we turned everything we learned into one script that you can run by hand or from SuperOps RMM.

Research

Duo publishes DuoLogSync (github.com/duosecurity/duo_log_sync), a small Python service that pulls logs from the Duo Admin API and sends them as JSON over TCP. The plan was simple: run DuoLogSync on the Wazuh manager, send its output to a syslog listener that only accepts local connections, and let Wazuh’s built-in JSON decoder do the rest. No agent, no public port, no custom decoder.

In practice, five things got in the way. They aren’t obvious from the documentation:

1. Stock Wazuh rule 86600 (Suricata) matches any JSON event that has both “timestamp” and “event_type” fields. Duo auth logs have both, so every event was captured by a level 0 rule and silently thrown away. Our rules now hang under 86600 as child rules.
2. Wazuh loads every rule file, stock and custom together, in alphabetical order. Naming the file 9999_duo_rules.xml makes sure it loads after the stock rules it depends on.
3. “action” is a reserved Wazuh field name, so a field match on it stops the whole ruleset from loading. Use the <action> tag or a dotted field like action.name instead.
4. DuoLogSync 2.4 retired the “adminaction” endpoint. Admin events now come from the “activity” log, which has a completely different JSON layout.
5. DuoLogSync opens one TCP connection and never reconnects. Every Wazuh manager restart quietly lost the next batch of logs. The fix is a systemd unit tied to the manager with PartOf=wazuh-manager.service.

The payoff showed up right away. The 180-day history pull surfaced twelve failed Active Directory syncs, all caused by a Duo Authentication Proxy outage. If an AD sync fails, a user you just disabled in AD can still pass Duo, so that’s a finding worth knowing about.

Variables

DuoIntegrationKey = The integration key of a Duo Admin API application with only “Grant read log” permission – i.e. DIXXXXXXXXXXXXXXXXXX
DuoSecretKey = The secret key for that application (mark this as a secure variable in SuperOps)
DuoApiHost = The API hostname from the same application – i.e. api-xxxxxxxx.duosecurity.com
DuoEndpoints = Optional. Which Duo logs to pull – default auth,telephony,activity
DuoOffsetDays = Optional. How many days of history to pull on the first run, maximum 180
DuoAction = Optional. install, status, resend or uninstall

Script Snippet

The full script handles prerequisite checks, backups, validation, automatic rollback, and a final check with wazuh-logtest. These are the core pieces:

# DuoLogSync config - single quotes are required by DLS
cat > /opt/duologsync/config.yml <<EOF
version: '1.0.0'
dls_settings:
  log_format: 'JSON'
  api:
    offset: $DLS_OFFSET_DAYS
  checkpointing:
    enabled: True
    directory: '/opt/duologsync/checkpoints'
servers:
  - id: 'wazuh'
    hostname: '127.0.0.1'
    port: 5140
    protocol: 'TCP'
account:
  ikey: '$DUO_IKEY'
  skey: '$DUO_SKEY'
  hostname: '$DUO_API_HOST'
  endpoint_server_mappings:
    - endpoints: ['auth', 'telephony', 'activity']
      server: 'wazuh'
EOF

# Local-only listener added to ossec.conf
<remote>
  <connection>syslog</connection>
  <port>5140</port>
  <protocol>tcp</protocol>
  <local_ip>127.0.0.1</local_ip>
  <allowed-ips>127.0.0.1</allowed-ips>
</remote>

# Duo auth events are claimed by Suricata rule 86600 - attach under it
<rule id="120000" level="0">
  <if_sid>86600</if_sid>
  <field name="txid">\.+</field>
  <field name="factor">\.+</field>
  <description>Duo: authentication event</description>
</rule>

# systemd: restart with the manager, wait for the listener first
[Unit]
After=wazuh-manager.service
PartOf=wazuh-manager.service
[Service]
ExecStartPre=/bin/bash -c 'until ss -ltn | grep -q "127.0.0.1:5140 "; do sleep 2; done'
ExecStart=/opt/duologsync/venv/bin/duologsync /opt/duologsync/config.yml
Restart=always

The complete script, the SuperOps edition, and the full ruleset (with alerts for MFA fraud reports, MFA fatigue, admin panel brute force, Duo configuration changes and AD sync failures, all tagged for NIST 800-171) are free on our GitHub: https://github.com/FarmhouseNetworking/Duo-Wazuh-LogSync
